INSTRUMENT
-
pH
-
redox
-
flöde
-
turbiditet
-
konduktivitet
| MODELS AVAILABLE |
| Functions |
LPH |
LPHS |
| Range |
0 ÷ 14pH
0 ÷ 1000mV |
| Resolution |
±0,01pH
±1mV |
| Display |
7 Segments |
| Controls |
Analogic |
| Calibration |
Manual |
| On/Off Set Points |
Two |
| Proportional Set Points |
No |
0 ÷ 20mA
or 4 ÷ 20mA |
| Input Impedance |
>1012 Ohm |
| On/Off Output |
2 Voltage Output |
| Chart recorder output |
0 ÷ 20mA
or 4 ÷ 20mA |
| Alarm |
Max dosing time alarm /
Voltage free contact relay (fuse protected) |
| Stand-by |
Input contact |
| Delay |
Programmable "Power-on"
delay |
| Max Resistive Load |
5A - 220 VAC |
| Power Supply |
24, 115, 230 VAC,
50-60Hz |
| Power Consumption |
10W |
| Fuse |
Instrument, output and
alarm fuse protection |
| Galvanic Isolation |
Upon demand |
| Casing Material |
ABS - IP65 |
| Mounting |
Wall |
| Dimensions |
225 x 215 x 125 mm |
| Net Weight |
1,2 Kg |
| Temperature Compensation |
Automatic / Manual |
